- Pan Rotation Angle: 360º Endless
- Pan Speed: Manual : 0.5º ~ 200º /sec (64step) / Preset : Max 360º/sec
- Tilt Rotation Angle: -2º ~ 90º
- Tilt Speed: Manual : 0.5º ~ 150º/sec (64step) / Preset : Max 300º/sec
- System Accuracy: 0.009º

- Preset: 220 positions
- Group TourMax. 8 Programmable group tours
- Auto Scan: Programable Auto scan
- Pattern: 8 Programmable Patterns (total 480 seconds)
- Sector: 8 selectable Sectors with 16 characters
- Home Position & Recover:Yes(Preset / Tour / Pattern / Scan)
- Password Protection: Yes
- Privacy Zone: 8
- Image Stabilizer: Yes
- WDR: Option
- SSNR: Yes
- DSS: Option
- BLC: On / Off
- HLC: On / Off
- Day & Night: AUTO / DAY / NIGHT
- Alarm Input: 4 alarms(with various programmable states)
- Alarm Actions:Activate preset, Group Tour, Pattern
- Aux Output: N/A
- Auto Flip: On/Off
- OSD Menu: Yes
- Communication: RS-485
- Protocol: Multiple Protocols

- Power Consumption: AC24V 1.5A 36W Max
- Power Supply:AC24V 50/60Hz 2A

- Image Sensor: 1/4" Interline Transfer CCD
- Total Image Pixels: NTSC : 811(H) x 508(V) 410K PAL : 795(H) x 596(V) 470K
- Horizontal Resolution:580TVL
- Lens: 37x F=1.6~3.9, f=3.5~129.5mm (Digital : 16X / Total :592X)
- Min. Illumination: 0.2Lux / F1.6(Color : 50IRE) 0.04Lux / F1.6 (B/W : ICR ON)
- Luminance : More than 50dB
- Video Output: Composite video output 75Ω Terminated

- Construction: Aluminum die casting
- Motor Type: Stepping motor (2 Phase)
- Micro Steps: 1/4 Micro Step
- Storage Temperature: -20ºC ~ 60ºC (-4ºF ~ 140ºF)
- Operating Temperature: -10°C ~50°C (-14ºF ~ 122ºF)
- Certifications: CE, FCC
