- Multiple function: Quadruplex
- OS: Embedded Linux
- Video Input: 8ch
- Video Output: 1 HDMI 1 VGA, 1 Composite, 1 Spot (Programmable)
- Audio Input/Output: 1 out (RCA)
- Alarm input/Output: 1
- Communication Port: RS-442 Ethernet (10/100 Base-T) USB 2.0
- Power: 12V/5A

- Compression:H.264
- Data Size: 0.06 ~ 0.7 Mbps/ch @30fps
- Live Display Resolution:720*480(NTSC)/720*576(PAL)
- Live Display Speed:Real Time
- Display split mode: 1,4,6,7,8,9,10,13,16
- Recording Speed: 120fps 120x480(NTSC), 100fps 720x576(PAL) | 240fps 720x240(NTSC), 200fps 720x288(PAL) | 480fps 360x240(NTSC) 400fps360x288 (PAL)
- Recording Mode: Continuous, Schedule, Motion, Alarm, Time limit.
- Recording Quality:Low, Middle, High, Super, Ultra
- Motion Detection:8*8(Selectable grids),20 Sensitivity Levels

- Search Method: Smarth search, date&time, event, log search
- Playback of Backup file: Mini Player(Auto Copy), EMS, AVI
- Playback Speed: Multi Level (Full frame reverse PB Supported)

- Backup Storage interface: 2 x USB 2.0 Network
- External Backup Device: External HDD,DVD-RW , Flash Memory Stick
- Internal HDD: Upto 2 Internal HDDs (W/O DVR-RW)
- DATA Archiving: Ethernet, Remote PC, External Recording device, FTP

- Network Interface: RJ 45/Ethernet
- Network Line: LAN, WAN, Internet
- Network Transmission Speed: Max.480fps
- Pre-Alarm/Post-Alarm: 0sec ~300sec / 10sec ~ 300sec
- DDNS Support: Unique, Public Method
- Event Routing: Source- Alarm, Motion, Video loss, System, Power loss, HDD failure, Fan Lock, Temperature | Action-Record, System buzzer, Alarm ready, Spot, PTZ

- Controls: Mouse, IR remote, Front Key,IE
- Dimension: 360(W) x 360(D) x 70(H)mm
- Weight: 2.4kg without HDD
- Power Consumption: 50W
- Operating Temperature: 0°C~40°C
